GESINT CUSTOM VERSION
DIN-rail digital temperature controller
Mod. K85-LCRRR-GE90
Input probe: PT100 or J/K/S thermocouple
Output: 3 relays (2x SPDT + 1x SPST)
Control: On-Off, 1°C hysteresis
Power supply: 24Vac/dc
Replace TLK35-LCRRR-90Reference manual

Dual display digital temperature controller
Mod. K39-LCR-GE90
Dual display for process and set-point temperature
Input probe: PT100 or J/K/S thermocouple
Output: 1 SPDT relays
Control: On-Off, 1°C hysteresis
Power supply: 24Vac/dc
Replace TLK39-LCR-90
 Reference manual

Dual display digital temperature controller
Mod. K39-LCRR-GE91
Dual display for process and set-point temperature
Input probe: PT100 or J/K/S thermocouple
Output: 2 SPDT relays
Control: On-Off, 1°C hysteresis
Power supply: 24Vac/dc
Replace TLK39-LCRR-91
 Reference manual

Digital panel meter
Mod. K38V-LV-G1
Input signal: 0÷10Vdc
4 digit display with or without decimal point
Power supply: 24Vac/dc
Reference manual

STANDARD PRODUCTS
Digital temperature controller
Mod. TLK38
Multiple input: J/K/S thermocouple, PT100, PTC, NTC, 0÷10V, 4÷20mA
Output: 2 relays or voltage for SSR driving
Control: On-Off, PID and programmable neutral zone
Standard power supply: 24Vac/dc, others on request (dimensions 33x75mm)
Reference manual

Digital temperature controller
Mod. TLK48
Multiple input: J/K/S thermocouple, PT100, PTC, NTC, 0÷10V, 4÷20mA
Output: 2 relays or voltage for SSR driving
Control: On-Off, PID and programmable neutral zone
Standard power supply: 24Vac/dc, others on request (dimensions 48x48mm)
Reference manual

Digital temperature controller
Mod. TLK35
Multiple input: J/K/S thermocouple, PT100, PTC, NTC, 0÷10V, 4÷20mA
Output: 2 relays or voltage for SSR driving
Control: On-Off, PID and programmable neutral zone
Standard power supply: 24Vac/dc, others on request (dimensions 4 DIN modules)
Reference manual

Dual display digital temperature controller
Mod. TLK39
Dual display for process and set-point temperature
Multiple input: J/K/S thermocouple, PT100, PTC, NTC, 0÷10V, 4÷20mA
Output: 2 relays or voltage for SSR driving
Control: On-Off, PID and programmable neutral zone
Standard power supply: 24Vac/dc, others on request (dimensions 33x75mm)
Reference manual

Dual display digital temperature controller
Mod. TLK49
Dual display for process and set-point temperature
Multiple input: J/K/S thermocouple, PT100, PTC, NTC, 0÷10V, 4÷20mA
Output: 2 relays or voltage for SSR driving
Control: On-Off, PID and programmable neutral zone
Standard power supply: 24Vac/dc, others on request (dimensions 48x48mm)
Reference manual

Dual display digital controller with universal input
Mod. TLK43
Dual display for process and set-point
Universal input: J/K/S thermocouple, PT100, PTC, NTC, 0÷10V, 4÷20mA
Output: up to 2 currentoltage and/or up to 4 relay/SSR
Control: On-Off, PID and programmable neutral zone
Standard power supply: 24Vac/dc, others on request (dimensions 48x48mm)
Reference manual

Digital panel meter
Mod. TLV38
Input: J/K/S thermocouple, PT100, PTC, NTC, mV, 0÷1V, 0÷10V, 4÷20mA
4 digit display with or without decimal point
Output: 2 relays or voltage for SSR driving
Standard power supply: 24Vac/dc, others on request (dimensions 33x75mm)
Reference manual

Accessories
Programming key
Mod. KEY01
Allow the memorisation and transfer of software configuration
Suitable for TLK and TLZ series of Tecnologic instruments
Power supply: 12Vdc with included power adapter
Reference manual
