Integrated Power Designs (IPD)是一家通过ISO 9001:2015认证的公司。

IPD是一家美国电源制造商，生产25-400瓦的AC-DC和DC-DC电源。自1985年4月成立以来，我们一直致力于按时交付优质产品，同时尽量减少对环境的影响。通过不断提高供电效率，减少对环境的影响。我们现在设计的产品具有90%的峰值效率，这些紧凑的解决方案是ITE，音频/视频，通信和医疗应用的理想选择。

具有1-4输出的产品平台允许最大的灵活性。输出可以配置为正、负或隔离。其他输出功能包括过功率保护，过压保护，电源故障警告和1号输出上的遥感。电源可以是开放式的，带机箱的，或者是全封闭的，带各种输入/输出连接器的机箱和盖板。在需要备用输出、远程抑制或低空载输入功率的情况下，请查看各个数据表的可用性。

我们的内部能力包括一个符合ISO 17025标准的研发实验室。新设计和修改的标准产品目前正在通过IEC/EN/UL/CSA 60950-1第二版ITE, IEC/EN/UL/CSA 62368-1第二版AV, ITE, CTE和IEC/EN/UL/CSA 60601-1第三版医疗认证。这是通过我们的TUV接受客户测试/监督制造商测试和UL客户测试数据计划实现的。产品符合最新的EMC标准，EN 60601-1-2第4版，由ISO 17025认证的第三方测试机构进行测试。

请咨询工厂定制电压和电流。

交流-直流电源交流-直流

电力供应

 IPD’s AC-DC power supplies range in power from 25 – 1000 watts and have 1 – 4 outputs. The units have 60601-1 and 62368-1 approvals. These power supplies are suitable for incorporating into medical, industrial, IT and audio/ video applications.
SRP Series25-100 Watts• Universal (85-264 VAC) Input
• 1 – 4 Outputs
• Medical and Industrial ApplicationsGRN Series45-360 Watts• Universal (85-264 VAC) Input
• 1 – 4 Outputs
• Medical and Industrial ApplicationsREL Series70-185 Watts• Universal (85-264 VAC) Input
• 1 – 4 Outputs
• Medical and Industrial Applications

CE Series150-225 Watts• Universal (85-264 VAC) Input
• 1 – 5 Outputs
• Medical and Industrial ApplicationsNXT Series100-1000 Watts• Universal (85-264 VAC) Input
• Single Output
• Medical and Industrial ApplicationsNXT-400M400 Watts• Universal (85-264 VAC) Input
• 2 – 4 Adjustable Outputs
• Medical and Industrial ApplicationsNXT-700700 Watts• Universal (85-264 VAC) Input
• 2 – 4 Adjustable Outputs
• Medical and Industrial Applications



IPD的输出额定功率在25-400W之间，可为医疗和工业应用提供广泛的交流-直流电源

DC-DC电源DC-DC

电力供应

 IPD’s DC-DC power supplies range in power from 70 – 185 watts and have 1 – 4 outputs. The DC1 input is 9-18 VDC, the DC2 input is 18-36 VDC and the DC4 input is 36-72VDC. The units have 60601-1 and 62368-1 approvals. These power supplies are suitable for incorporating into medical, industrial, IT and audio/ video applications.  Reinforced

Insulation is provided between primary and secondary circuits.  If your application requires either a DC or an AC input, this series is mounting

and output compatible with their REL series counterparts.

DC1-8080 Watts                    • 9-18 VDC Input                    • 1 – 4 Outputs                    • Medical and Industrial Applications

DC2-7070 Watts• 18-36 VDC Input• 1 – 4 Outputs• Medical and Industrial ApplicationsDC2-110110 Watts• 18-36 VDC Input• 1 – 4 Outputs• Medical

and Industrial ApplicationsDC2-150150 Watts•

18-36 VDC Input• 1 – 4 Outputs• Medical and Industrial ApplicationsDC2-185185 Watts• 18-36 VDC Input• 1 – 4 Outputs• Medical and Industrial Applications



DC4-7070 Watts• 36-72 VDC Input• 1 – 4 Outputs• Medical and Industrial ApplicationsDC4-110110 Watts• 36-72 VDC Input• 1 – 4 Outputs• Medical

and Industrial ApplicationsDC4-150150 Watts•

36-72 VDC Input• 1 – 4 Outputs• Medical and Industrial ApplicationsDC4-185185 Watts• 36-72 VDC Input• 1 – 4 Outputs• Medical and Industrial Applications



IPD提供70-185W范围的DC-DC电源，输入电压为18- 36vdc或36- 72vdc。在一次回路和二次回路之间提供强化绝缘

REL-110-4001

REL-110-4002

REL-110-4003

REL-110-4004

REL-110-4005

REL-110-4006

REL-110-4007

REL-110-4009

REL-110-3001

REL-110-3002

REL-110-3003

REL-110-3004

REL-110-2001

REL-110-2002

REL-110-2003

REL-110-2004

REL-110-2005

REL-110-2006

REL-110-1001

REL-110-1002

REL-110-1003

REL-110-1004

REL-110-1005

REL-110-1006

REL-110-1007

REL-110-1008

DC4-150-4001

DC4-150-4002

DC4-150-4003

DC4-150-4004

DC4-150-4005

DC4-150-4006

DC4-150-4007

DC4-150-3001

DC4-150-3002

DC4-150-2001

DC4-150-2002

DC4-150-2003

DC4-150-2004

DC4-150-2005

DC4-150-1001

DC4-150-1002

DC4-150-1003

DC4-150-1004

DC4-150-1005

DC4-150-1006

DC4-150-1007

DC4-150-1008

SRP-25-3001

SRP-25-3002

SRP-25-3003

SRP-25-2001

SRP-25-2002

SRP-25-2003

SRP-25-2004

SRP-25-2005

SRP-25-1001

SRP-25-1002

SRP-25-1003

SRP-25-1004

SRP-25-1005

SRP-25-1006

DC1-80-4001

DC1-80-4002

DC1-80-4003

DC1-80-4004

DC1-80-4005

DC1-80-4006

DC1-80-3001

DC1-80-3002

DC1-80-2001

DC1-80-2002

DC1-80-2003

DC1-80-2004

DC1-80-1001

DC1-80-1002

DC1-80-1003

DC1-80-1004

DC1-80-1005

DC1-80-1006

DC1-80-1007

DC2-110-4001

DC2-110-4002

DC2-110-4003

DC2-110-4004

DC2-110-4005

DC2-110-4006

DC2-110-4007

DC2-110-3001

DC2-110-3002

DC2-110-3003

DC2-110-2001

DC2-110-2002

DC2-110-2003

DC2-110-2004

DC2-110-2005

DC2-110-1001

DC2-110-1002

DC2-110-1003

DC2-110-1004

DC2-110-1005

DC2-110-1006

DC2-110-1007

DC2-110-1008
